Pill Automatic Tablet Coating Machine For Chocolate Nut Peanut

  • 1
  • 2

Brand Name : STH, TIANHE

Model Number : GBS-250

Certification : CE, ISO, GMP

Place of Origin : SHANGHAI, CHINA

MOQ : 1 UNIT

Price : Negotiation

Delivery Time : 30 - 45 days

Packaging Details : Fumigation free export packing case

product name : Pill Automatic Tablet Coating Machine For Chocolate Nut Peanut

Type : pharmaceutical coating machine

Usage : Foods, Pharmaceutical

Loading Capacity : 150kgs

Coating drum rotating speed : 2-18r/min

Air exhaust flow : 5210-7419 m3/h

Hot air flow : 2356 m3/h

Air consumption : 0.6m3/min

After-sales Service : Free spare parts, Field installation, commissioning

Voltage : 380V

Contact Now

Pill Automatic Tablet Coating Machine For Chocolate Nut Peanut

Pill Automatic Tablet Coating Machine For Chocolate Nut Peanut Quick Details:

- 200kg per batch

- Explosion-proof

- adopts imported PLC man-machine interface

- automatic regulation negative pressure

Pill Automatic Tablet Coating Machine For Chocolate Nut Peanut Application

GBS series high-efficient sugarcoating and film coating equipment is mainly used in the pharmaceutical and foodstuff industries. This novel equipment, featured by high-efficient, energy-saving, safety, cleanliness and easy operation, is essential for Sugar, organic film, water soluble film-coating of tablets, pills and sweets.

PRINCIPLE:

The tablet cores to be film coated make continuous complicated orbital motion within the closed rotating drum under the action of a streamline guide plate. During the movement, coating medium is automatically sprayed according to the technological process and rational technological parameters assigned, coating, So that the coating medium sprayed on the surface of tablet cores, thus forming a solid and smooth surface film.

Characteristics:

  • The GBS series are made in compliance with the GMP standard in the pharmaceutical industry.
  • The case, coating dram, heat-air supplying cabinet and spray devices as well as every part in contact with medicine are wholly made of stainless steel.
  • The whole operation process is controlled either by a programming system of the microprocessor or manually, the control system has multi-functions of application programs, operation mode selection, drying control and multiple display.
  • Explosion-protecting devices are also equipped for the organic solvent for organic film coating.
  • With closed operation, neither dust flying nor spray splashing will appear.
  • Coating medium spraying, drying and exhausting can be carried out simultaneously for film coating, the whole processing van be completed only in 1-2 hours and for sugar coating, in 4-5 hours.
  • Equipped with an automatic material charge and discharge device.

Main technical specifications

Model GBS-40 GBS-75 GBS-150
Max. load capacity (kg) 40 75 150
Cylinder dimension (mm) 820 950 1200
Material’s inlet dimension 340 380 480
Roller speed(times/min) 3 - 22 3 - 22 3 - 16
Main machine power(kw) 1.1 1.5 2.2
Main machine weight(kw) 550 750 900
Main machine overall size (L*W*H mm) 1180*850*1530 1390*1050*1720 1770*1310*2200
Hot air cabinet power (kw) 1.1 1.5 2.2

Hot air cabinet

overall size

(L*W*H mm)

810*700*1830 900*715*2080 1080*820*2500
hot air cabinet weight(kg) 300 350 400
Air exhauster power(kw) 2.2 3 5.5
Air exhauster overall size (L*W*H mm) 730*730*1660 830*830*1850 1140*110*2120
Air exhaust weight (kg) 300 350 500
Stirrer power (kw) 3 4 4
Hot air cabinet volume (m3/h) 1600 2356 3517
Air exhaust volume (m³/h) 3517 5268 7419
Stirring barrel volume(L) 30 50 65

Pill Automatic Tablet Coating Machine For Chocolate Nut Peanut

Q1.What do you have any training?

We can train your staff to use our machine properly. It means that we offer Customers Training, teaching how to use the systems most efficiently and safely as well as how to maintain optimal operational productivity.

Q2.what's payment terms ,trade terms you accept ?

Usually we appreciate T/T 30% deposit , then 70% balance is paid before shipment , we usually offer fob ningbo price .but we also accept other way like L/C , wetern union ,and do CFR&CIF etc.

Q3.does it easy to operate and what can i do if it doesn't work?

First ,our machine is stable and easy to operate by one man ,what you do is just learn some basic thing like how to operate PLC .And we will sent you manual and video ,we suggest you to come to visit our factory to learn more thing by yourself , and if there is something goes wrong , you can call us ,video-chat ,email us .And we will give solutions within 36 hrs .Our engineer also can be distributed to overseas as you required.

Keywords:

tablet coating machine, film coating machine, tablet coater


Product Tags:

pill coating machine



tablet coater machine


Quality Pill Automatic Tablet Coating Machine For Chocolate Nut Peanut wholesale

Pill Automatic Tablet Coating Machine For Chocolate Nut Peanut Images
